Description
WEG power factor correction capacitors were designed using self-healing metallized polypropylene film, have security protection against internal over pressure and lower dielectric losses.
| Complement | Heavy Duty |
|---|---|
| Reactive power | 15.0 kVAr |
| Rated operational voltage Ue | 220V60HZ |
| Operational frequency | 60 Hz |
| Terminal type | Screw |
| Series | F |
Attributes
| Series | F |
|---|---|
| Rated capacitance | 274.0 µF |
| Capacitance tolerance | ±5% |
| Lifespan | 150.000 h |
| Temperature class | -25/D |
| Max. short circuit capacity | 10 kA |
| Discharge resistance conection | Fast-on |
| Impregnation | Polyurethane resin |
| Protection degree | IP20 |
| Gross weight | 2,174 kg / 4.793 lb |
