Description
| Standard | NEMA MG-1 |
|---|---|
| Frame | 184TC |
| Frequency | 60 Hz |
| Number of poles | 4 |
| Degree of Protection | IP69K |
| Synchronous speed | 1800 rpm |
| Flange | C |
| Mounting | F-1/B34R(D) |
| Terminal box¹ | Left position |
| Enclosure | TEFC |
Attributes
| Standard | NEMA MG-1 |
|---|---|
| Degree of Protection | IP69K |
| Mounting | F-1/B34R(D) |
| Output rating | 3 HP |
| Enclosure | TEFC |
| Frequency | 60 Hz |
| Flange | C |
| Frame Material | Stainless steel |
| Efficiency | NEMA Premium Efficiency |
| Motor Application | WASHDOWN |
| Terminal box¹ | Left position |
| Frame | 184TC |
| Voltage | 230/460 V |
| Synchronous speed | 1800 rpm |
| Number of Poles | 04 |
| Design | B |
| Insulation Class | F |
| Duty Cycle | S1 |
| Rotation¹ | Both (CW and CCW) |
