Description
- Capacitor Start
- General Purpose Single Phase
- Totally Enclosed Fan Cooled (TEFC)
- Rigid Base
- Reversible Rotation
Specifications
| Model_Number | AF72 |
|---|---|
| PRODUCT NAME | 1 HP - TE - 1740 |
| PHASETYPE | 1_PHASE |
| MOTOR ENCLOSURE | TE |
| HORSEPOWER | 1 |
| POLES | 4 |
| NUMBER SPEEDS | 1 |
| RPM | 1740 |
| RPM 2 | 1740 |
| HERTZ | 60 |
| VOLTS PRIMARY | 115/230 |
| VOLTS | 230 |
| VOLTS 2 | 115 |
| FRME | 182 |
| ASSEMBLY POSITION | F-1 |
| MOTOR TYPE | SM |
| OPPOSITE END BEARING | 6205-2Z-J/C3 |
| SHAFT END BEARING | 6206-2Z-J/C3 |
| AMBIENT | 40 |
| SERVICE FACTOR | 1 |
| STARTCAPMFD | N\A |
| SHIPPING WEIGHT | 72 |
| INSULATION CLASS | F |
| KVA CODE LETTER | K |
| NEMA NOMINAL EFFICIENCY | 71.7 |
| FULL LOAD AMPS PRIMARY | 13.8/6.9 |
