Description
- General Purpose
- Three Phase Totally Enclosed Fan Cooled (TEFC)
- HOSTILE DUTYâ„¢
- Premium Efficient
Specifications
| Model_Number | DL64 |
|---|---|
| PRODUCT NAME | 40 HP - TE - 3565 |
| PHASETYPE | 3_PHASE |
| MOTOR ENCLOSURE | TE |
| HORSEPOWER | 40 |
| KILOWATTS | 29.8 |
| POLES | 2 |
| NUMBER SPEEDS | 1 |
| RPM | 3565 |
| RPM 2 | 3565 |
| HERTZ | 60 |
| HERTZ 2 | 50 |
| VOLTS PRIMARY | 230/460 |
| VOLTS | 460 |
| VOLTS 2 | 230 |
| FRME | 324 |
| SHAFT CODE | TS |
| MOUNTING | HORZ-FOOTED |
| ASSEMBLY POSITION | F1 |
| MOTOR TYPE | CTE |
| OPPOSITE END BEARING | 6311-2Z-J/C3 |
| SHAFT END BEARING | 6311-2Z-J/C3 |
| AMBIENT | 40 |
| SERVICE FACTOR | 1.15 |
| STARTCAPMFD | N\A |
| SHIPPING WEIGHT | 460 |
| INSULATION CLASS | F |
| KVA CODE LETTER | G |
| NEMA NOMINAL EFFICIENCY | 93 |
| FULL LOAD AMPS PRIMARY | 90.0/45.0 |
| SERVICE FACTOR AMPS PRIMARY | 104.0/52.0 |
