Description
- Special Application Farm
- Agriculture Single & Three Phase
- Direct Drive Poultry Fan
Specifications
| Model_Number | K063EER4570021B |
|---|---|
| PRODUCT NAME | 1 HP - - 850 |
| PHASETYPE | 1_PHASE |
| HORSEPOWER | 1 |
| KILOWATTS | 0.8 |
| POLES | 8 |
| NUMBER SPEEDS | 1 |
| RPM | 850 |
| HERTZ | 60 |
| VOLTS PRIMARY | 230 |
| VOLTS | 230 |
| FRME | 56 |
| SHAFT CODE | YZ |
| STATOR DIAMETER | 6.3 |
| STACK | 4.5 |
| MOTOR TYPE | FHP |
| AMBIENT | 40 |
| ROTATION | CCW LEAD END |
| SERVICE FACTOR | 1 |
| RUNCAPMFD | 25 |
| RUNCAPVOLTS | 370 |
| SHIPPING WEIGHT | 32 |
| BREAKDOWN TORQUE | 148.9 |
| BREAKDOWN TORQUE UOM | OZFT |
| LOCKED ROTOR TORQUE | 25.46 |
| LOCKED ROTOR TORQUE UOM | OZFT |
| KVA CODE LETTER | A |
| LOCKED ROTOR AMPS | 11.63 |
| FULL LOAD AMPS PRIMARY | 5.8 |
| SERVICE FACTOR AMPS PRIMARY | 5.8 |
