Description
- Special Application Farm
- Single Phase
- Dust Tight & Auger Duty Motors
- Cap Start
- Auger Duty
Specifications
| Model_Number | C055JYJ4744024B |
|---|---|
| PRODUCT NAME | .5 HP - TEFC - 1725 |
| PHASETYPE | 1_CAPACITOR START |
| MOTOR ENCLOSURE | TEFC |
| HORSEPOWER | .5 |
| KILOWATTS | 0.4 |
| POLES | 4 |
| NUMBER SPEEDS | 1 |
| RPM | 1725 |
| RPM 2 | 1425 |
| HERTZ | 60 |
| HERTZ 2 | 50 |
| VOLTS PRIMARY | 115/230 V |
| VOLTS | 115 |
| VOLTS 2 | 230 |
| FRME | 56 |
| SHAFT CODE | YZ |
| STATOR DIAMETER | 5.5 |
| STACK | 2.75 |
| MOUNTING | FLANGE |
| MOTOR TYPE | FHP |
| OPPOSITE END BEARING | BALL |
| SHAFT END BEARING | BALL |
| AMBIENT | 40 |
| ROTATION | REVERSIBLE |
| SERVICE FACTOR | 1 |
| STARTCAPMFD | 473 |
| SHIPPING WEIGHT | 22 |
| THERMAL PROTECTION | MANUAL RESET |
| BREAKDOWN TORQUE | 79.15 |
| BREAKDOWN TORQUE UOM | OZFT |
| LOCKED ROTOR TORQUE | 113.1 |
| LOCKED ROTOR TORQUE UOM | OZFT |
| INSULATION CLASS | B |
| KVA CODE LETTER | M |
| LOCKED ROTOR AMPS | 43.85 |
| FULL LOAD AMPS PRIMARY | 8.6/4.3 & 10.4/5.4 |
| SERVICE FACTOR AMPS PRIMARY | 8.6/4.3 & 10.4/5.4 |
