Description
- 56 C Flange Pool & Spa Motors
- Switchless Design 6.5" Diameter Category "S" & "J"
- Premium Efficient
- Full Service Factor Full Rated Soft Start
Specifications
| Model_Number | R063DMJ0183013J |
|---|---|
| PRODUCT NAME | .75 HP - - 3450 |
| PHASETYPE | 1_PHASE |
| HORSEPOWER | .75 |
| HORSEPOWER 2 | 0.1 |
| KILOWATTS | 0.6 |
| POLES | 2 |
| POLES 2 | 4 |
| NUMBER SPEEDS | 2 |
| RPM | 3450 |
| RPM 2 | 1725 |
| HERTZ | 60 |
| VOLTS PRIMARY | 230 |
| VOLTS | 230 |
| FRME | 56 |
| SHAFT CODE | C |
| STATOR DIAMETER | 6.3 |
| STACK | 2 |
| MOTOR TYPE | FHP |
| AMBIENT | 50 |
| ROTATION | CW LEAD END |
| RUNCAPMFD | 25 |
| RUNCAPVOLTS | 370 |
| SHIPPING WEIGHT | 28 |
| BREAKDOWN TORQUE | 77.32 |
| BREAKDOWN TORQUE UOM | OZFT |
| LOCKED ROTOR TORQUE | 10.12 |
| LOCKED ROTOR TORQUE UOM | OZFT |
| KVA CODE LETTER | A |
| LOCKED ROTOR AMPS | 28.46 |
| FULL LOAD AMPS PRIMARY | 5.8/2.3 |
