Description
- Special Application Close Coupled Pump
- Three Phase
- Open Dripproof (ODP)
- Premium Efficient
- JM Shaft - Footed
Specifications
| Model_Number | HA74 |
|---|---|
| PRODUCT NAME | 20 HP - ODP - 3540 |
| PHASETYPE | 3_PHASE |
| MOTOR ENCLOSURE | ODP |
| HORSEPOWER | 20 |
| KILOWATTS | 14.9 |
| POLES | 2 |
| NUMBER SPEEDS | 1 |
| RPM | 3540 |
| HERTZ | 60 |
| VOLTS PRIMARY | 575 |
| VOLTS | 575 |
| FRME | 254 |
| SHAFT CODE | JM |
| MOUNTING | HORZ-FOOTED |
| ASSEMBLY POSITION | F1 |
| MOTOR TYPE | DE4 |
| OPPOSITE END BEARING | 6309-2Z-J/C3 |
| SHAFT END BEARING | 6310-2Z-J/C3 |
| AMBIENT | 40 |
| SERVICE FACTOR | 1.15 |
| STARTCAPMFD | N\A |
| SHIPPING WEIGHT | 150 |
| BREAKDOWN TORQUE | 247 |
| BREAKDOWN TORQUE UOM | PERCENT OF FLT |
| LOCKED ROTOR TORQUE | 166 |
| LOCKED ROTOR TORQUE UOM | PERCENT OF FLT |
| INSULATION CLASS | F |
| KVA CODE LETTER | G |
| LOCKED ROTOR AMPS | 117.4 |
| NEMA NOMINAL EFFICIENCY | 91 |
| FULL LOAD AMPS PRIMARY | 18.7 |
| SERVICE FACTOR AMPS PRIMARY | 21.5 |
