Description
- Special Application
- Three Phase Open Dripproof (ODP)
- Elevator Motor
- Dry Hydraulic Motor
Specifications
| Model_Number | BW59 |
|---|---|
| PRODUCT NAME | 60 HP - ODP - 1770 |
| PHASETYPE | 3_PHASE |
| MOTOR ENCLOSURE | ODP |
| HORSEPOWER | 60 |
| KILOWATTS | 44.7 |
| POLES | 4 |
| NUMBER SPEEDS | 1 |
| RPM | 1770 |
| HERTZ | 60 |
| VOLTS PRIMARY | 200 |
| VOLTS | 200 |
| FRME | 326 |
| SHAFT CODE | T |
| MOUNTING | HORZ-FOOTED |
| ASSEMBLY POSITION | F1 |
| MOTOR TYPE | D |
| OPPOSITE END BEARING | 6211-2Z-J/C3 |
| SHAFT END BEARING | 6311-2Z-J/C3 |
| AMBIENT | 40 |
| SERVICE FACTOR | 1 |
| STARTCAPMFD | N\A |
| SHIPPING WEIGHT | 460 |
| BREAKDOWN TORQUE | 198 |
| BREAKDOWN TORQUE UOM | PERCENT OF FLT |
| LOCKED ROTOR TORQUE | 153 |
| LOCKED ROTOR TORQUE UOM | PERCENT OF FLT |
| INSULATION CLASS | F |
| KVA CODE LETTER | E |
| LOCKED ROTOR AMPS | 781 |
| NEMA NOMINAL EFFICIENCY | 92.4 |
| FULL LOAD AMPS PRIMARY | 160 |
