Description
- Special Application Washdown
- Three Phase Totally Enclosed
- All Stainless Steel
- C Face Footless
Specifications
| Model_Number | DD44 |
|---|---|
| PRODUCT NAME | 1.5 HP - TEFC - 1755 |
| PHASETYPE | 3_PHASE |
| MOTOR ENCLOSURE | TEFC |
| HORSEPOWER | 1.5 |
| KILOWATTS | 1.1 |
| POLES | 4 |
| NUMBER SPEEDS | 1 |
| RPM | 1755 |
| RPM 2 | 1755 |
| RPM 3 | 1740 |
| HERTZ | 60 |
| VOLTS PRIMARY | 208-230/460 |
| VOLTS | 460 |
| VOLTS 2 | 230 |
| VOLTS 3 | 208 |
| FRME | 145 |
| SHAFT CODE | TC |
| MOUNTING | HORZ-FOOTLESS |
| ASSEMBLY POSITION | NA |
| MOTOR TYPE | SSEF |
| OPPOSITE END BEARING | 6203-2RS-J/C3 |
| SHAFT END BEARING | 6205-2RS-J/C3 |
| AMBIENT | 40 |
| ROTATION | DUAL |
| SERVICE FACTOR | 1.15 |
| STARTCAPMFD | N\A |
| SHIPPING WEIGHT | 47 |
| BREAKDOWN TORQUE | 479 |
| BREAKDOWN TORQUE UOM | PERCENT OF FLT |
| LOCKED ROTOR TORQUE | 359 |
| LOCKED ROTOR TORQUE UOM | PERCENT OF FLT |
| INSULATION CLASS | F |
| KVA CODE LETTER | M |
| LOCKED ROTOR AMPS | 19.2 |
| NEMA NOMINAL EFFICIENCY | 86.5 |
| FULL LOAD AMPS PRIMARY | 4.4-4.1/2.1 |
| SERVICE FACTOR AMPS PRIMARY | 4.9-4.6/2.3 |
