Description
Specs
| Armature Voltage | 180 V |
|---|---|
| Base Speed | 1750 rpm |
| Enclosure | TEFC |
| Frame | D112D |
| Frame Material | Steel |
| Output Power | 3.000 HP |
| XP Class and Group | None |
| Agency Approvals | CE CSA UR WEEE |
| Ambient Temperature | 40 °C |
| Armature Current | 14.0 a |
| Armature Inertia | 107.110 lb-ft2 |
| Base Indicator | Rigid |
| Bearing Grease Type | Polyrex EM (-20F +300F) |
| Drip Cover | No Drip Cover |
| Duty Rating | CONT |
| Feedback Device | NO FEEDBACK |
| Frame Prefix | D |
| Heater Indicator | No Heater |
| Insulation Class | F |
| Lifting Lugs | Standard Lifting Lugs |
| Motor Lead Exit | Ko Box |
| Motor Lead Termination | Flying Leads |
| Motor Lead Quantity/Wire Size | 2 @ 12 AWG |
| Mounting Arrangement | F1 |
| Overall Length | 24.57 IN |
| Product Family | General Purpose |
| Pulley End Bearing Type | Sealed Bearing |
| RoHS Status | ROHS COMPLIANT |
| Service Factor | 1.00 |
| Shaft Diameter | 1.103 IN |
| Shaft Extension Location | Pulley End |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Rotation | Reversible |
| Shaft Slinger Indicator | No Slinger |
| Motor Standards | IEC |
| XP Division | Not Applicable |
Drawings
Nameplate
| CAT.NO. | VP3603D |
|---|---|
| SPEC. | 36P182Z507 |
| HP | 2.2KW |
| RPM | 1750 1/MIN |
| FRAME | D112D |
| ARM V | 180 |
| INSUL | F |
| DUTY | CONT |
| BRG/DE | 6206 |
| BRUSHES | 2/BP5031A01 |
| BLANK | IP44 IC411 56KG |
| APRV-CE | Y |
Performance
| Rated Load | |||||||||
|---|---|---|---|---|---|---|---|---|---|
