Description
Specs
| Catalog Number | IDCRPM18154 |
|---|---|
| Enclosure | TEFC |
| Frame | FL1844Z |
| Frame Material | Exposed Laminations |
| Frequency | 60.00 Hz |
| Motor Letter Type | CP |
| Output @ Frequency | 15.000 HP @ 60 HZ |
| Phase | 3 |
| Synchronous Speed @ Frequency | 1800 RPM @ 60 HZ |
| Voltage @ Frequency | 460.0 V @ 60 HZ |
| Agency Approvals | CCSA US NEMA PREMIUM NEMA_PREMIUM |
| Auxillary Box | No Auxillary Box |
| Base Indicator | Rigid |
| Bearing Grease Type | Polyrex EM (-20F +300F) |
| Constant Torque Speed Range | 1-60 |
| Current @ Voltage | 15.000 A @ 460.0 V |
| Duty Rating | CONT |
| Feedback Device | NO FEEDBACK |
| High Voltage Full Load Amps | 15.0 a |
| Frame Prefix | FL |
| Heater Indicator | No Heater |
| Insulation Class | H |
| IP Rating | IP54 |
| KVA Code | G |
| Mounting Arrangement | F3 |
| Overall Length | 23.26 IN |
| Product Family | Blower - Centrifugal |
| Pulley End Bearing Type | Ball |
| Pulley Face Code | Other |
| Service Factor | 1.15 |
| Shaft Diameter | 1.375 IN |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Rotation | Reversible |
| Speed | 1800 rpm |
| Motor Standards | NEMA |
| Starting Method | Full Voltage |
| Thermal Device - Bearing | None |
| Thermal Device - Winding | Normally Closed Thermostat |
Drawings
Nameplate
| CAT.NO. | IDCRPM18154 |
|---|---|
| AMB. | 40 |
| NEMA NOM. EFF | 94.9 |
| D.E. BRG. | 45BC02J30X |
Performance
| Rated Load |
|---|
