Description
Specs
| Catalog Number | FPM2562T-4 |
|---|---|
| Enclosure | DP |
| Frame | 444TS |
| Frame Material | Iron |
| Frequency | 50.00 Hz 60.00 Hz |
| Motor Letter Type | Three Phase |
| Output @ Frequency | 200.000 HP @ 60 HZ 150.000 HP @ 50 HZ |
| Phase | 3 |
| Synchronous Speed @ Frequency | 3000 RPM @ 50 HZ |
| Voltage @ Frequency | 380.0 V @ 50 HZ 460.0 V @ 60 HZ |
| XP Class and Group | None |
| XP Division | Not Applicable |
| Agency Approvals | CULUS CCSAUSEEV |
| Ambient Temperature | 40 °C |
| Auxillary Box | No Auxillary Box |
| Base Indicator | Rigid |
| Bearing Grease Type | Polyrex EM (-20F +300F) |
| Current @ Voltage | 212.000 A @ 380.0 V 232.000 A @ 460.0 V |
| Design Code | B |
| Drip Cover | No Drip Cover |
| Duty Rating | CONT |
| Efficiency @ 100% Load | 94.5 % |
| Feedback Device | NO FEEDBACK |
| High Voltage Full Load Amps | 212.0 a |
| Heater Indicator | No Heater |
| Insulation Class | F |
| Inverter Code | Not Inverter |
| KVA Code | E |
| Lifting Lugs | No Lifting Lugs |
| Motor Lead Quantity/Wire Size | 12 @ 6 AWG |
| Motor Type | A44048M |
| Mounting Arrangement | F1 |
| Number of Poles | 2 |
| Overall Length | 35.88 IN |
| Power Factor | 85 |
| Product Family | Other |
| Pulley End Bearing Type | Ball |
| Pulley Face Code | Standard |
| Service Factor | 1.15 |
| Shaft Diameter | 2.375 IN |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Rotation | Reversible |
| Shaft Slinger Indicator | No Slinger |
| Speed | 2965 rpm 3560 rpm |
| Speed Code | Single Speed |
| Motor Standards | NEMA |
| Starting Method | Wye Start - Delta Run |
| Thermal Device - Bearing | None |
| Thermal Device - Winding | None |
Drawings
Nameplate
| CAT.NO. | FPM2562T-4 |
|---|---|
| SPEC. | P44G1851 |
| HZ | 60 |
| VOLTS | 460 |
| AMPS | 232 |
| EFF | 94.5 |
| RATING | 40C AMB-CONT |
Performance
| Rated Load |
|---|
