Baldor ECP49404T-5 400HP, 1785RPM, 3PH, 60HZ, L449T, TEFC, F1

BaldorSKU: ECP49404T-5

Dropship

Get it by Wed, Nov 26 - Mon, Dec 01

Price:
Sale price$67,735.07

Description

Specs
Catalog Number ECP49404T-5
Enclosure TEFC
Frame L449T
Frame Material Iron
Frequency 60.00 Hz
Motor Letter Type Three Phase
Output @ Frequency 400.000 HP @ 60 HZ
Phase 3
Synchronous Speed @ Frequency 1800 RPM @ 60 HZ
Voltage @ Frequency 575.0 V @ 60 HZ
XP Class and Group None
XP Division Division II
Agency Approvals CSA EEV
Ambient Temperature 40 °C
Auxillary Box No Auxillary Box
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Constant Torque Speed Range 30-60
Current @ Voltage 356.000 A @ 575.0 V
Design Code B
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 96.2 %
Enclosure Modification Severe Duty Features
Feedback Device NO FEEDBACK
High Voltage Full Load Amps 356.0 a
Frame Prefix L
Heater Indicator No Heater
Insulation Class F
Inverter Code Inverter Ready
IP Rating NONE
KVA Code G
Motor Lead Quantity/Wire Size 12 @ 1 AWG
Motor Type A44208M
Mounting Arrangement F1
Number of Poles 4
Overall Length 60.47 IN
Power Factor 88
Product Family General Industrial
Pulley End Bearing Type Ball
Pulley Face Code Standard
Service Factor 1.15
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator Shaft Slinger
Speed 1785 rpm
Speed Code Single Speed
Motor Standards NEMA
Starting Method Direct on line
Thermal Device - Bearing None
Thermal Device - Winding None
XP Temp Code T2C
Drawings
Nameplate
CAT NO ECP49404T-5
HP 400
FRAME L449T
D.E. BRG.DATA 6318
D.E. BRG. 90BC03J30X
O.D.E. BRG. 90BC03J30X
3/4 LOAD EFF. 96.3
TEMP CODE T2C
CHP HZ 60-90
INVERTER-TEMP-CODE T2C
Performance
Rated Load
Parts
