Description
Specs
| Armature Voltage | 230 V |
|---|---|
| Base Speed | 2500 rpm |
| Enclosure | DPFG |
| Field Voltage | 230 V |
| Frame | 1810AT |
| Frame Material | Steel |
| Output Power | 5.000 KW |
| Agency Approvals | CSA |
| Ambient Temperature | 40 °C |
| Armature Current | 21.7 a |
| Base Indicator | Rigid |
| Bearing Grease Type | No Grease |
| Drip Cover | No Drip Cover |
| Duty Rating | CONT |
| Feedback Device | NO FEEDBACK |
| Field Winding Type | COMPOUND |
| Heater Indicator | No Heater |
| Insulation Class | F |
| Lifting Lugs | Standard Lifting Lugs |
| Mounting Arrangement | F1 |
| Overall Length | 21.45 IN |
| Shaft Diameter | 1.125 IN |
| Shaft Extension Location | Pulley End |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Slinger Indicator | No Slinger |
| Motor Standards | NEMA |
| Thermal Device - Bearing | None |
Drawings
Nameplate
| CAT.NO. | DMG2305 |
|---|---|
| KW | 5KW |
| ARM VOLTS | 230 |
| FIELD VOLTS | 230 |
| ENCL | DPFG |
| O.D.E. BRG. | 6205 |
Performance
| Rated Load |
|---|
