Specs
| Armature Voltage | 500 V |
|---|---|
| Base Speed | 1750 rpm |
| Enclosure | TEFC |
| Field Voltage | 300 V |
| Frame | 259AT |
| Frame Material | Steel |
| Output Power | 10.000 HP |
| Agency Approvals | CSA |
| Ambient Temperature | 40 °C |
| Armature Current | 16.3 a |
| Base Indicator | Rigid |
| Bearing Grease Type | Polyrex EM (-20F +300F) |
| Drip Cover | No Drip Cover |
| Duty Rating | CONT |
| Feedback Device | NO FEEDBACK |
| Field Winding Type | STR. SHUNT |
| Heater Indicator | No Heater |
| Insulation Class | F |
| Lifting Lugs | Standard Lifting Lugs |
| Mounting Arrangement | F1 |
| Overall Length | 36.53 IN |
| Service Factor | 1.00 |
| Shaft Diameter | 1.624 IN |
| Shaft Extension Location | Double Shaft |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Slinger Indicator | No Slinger |
| Motor Standards | NEMA |
| Thermal Device - Bearing | None |
Drawings
Nameplate
| CAT.NO. | D5510P |
|---|---|
| HP | 10 |
| ARM V | 500 |
| FLD V | 300/150 |
| ENCL | TEFC |
| P CODE | D |
| O.D.E. BRG. | 6207 |
Performance
| Rated Load |
|---|
