Description
Specs
| Armature Voltage | 500 V |
|---|---|
| Base Speed | 1750 rpm |
| Enclosure | DPFG |
| Field Voltage | 150 V 300 V |
| Frame | 366AT |
| Frame Material | Steel |
| Output Power | 75.000 HP |
| Agency Approvals | CSA |
| Ambient Temperature | 40 °C |
| Armature Current | 123.0 a |
| Base Indicator | Rigid |
| Duty Rating | CONT |
| Field Winding Type | STAB SHUNT |
| Insulation Class | F |
| Mounting Arrangement | F1 |
| Service Factor | 1.00 |
| Shaft Diameter | 2.375 IN |
| Motor Standards | NEMA |
Drawings
Nameplate
| CAT.NO. | D5075P |
|---|---|
| HP | 75 |
| ARM V | 500 |
| FLD V | 150/300 |
| ENCL | DPFG |
| P CODE | D |
| O.D.E. BRG. | 6211 |
Performance
| Rated Load |
|---|
