Description
Specs
| Armature Voltage | 500 V |
|---|---|
| Base Speed | 1750 rpm |
| Enclosure | DP |
| Field Voltage | 300 V |
| Frame | LC2512ATZ |
| Frame Material | Exposed Laminations |
| Output Power | 50.000 HP |
| Agency Approvals | CCSA US |
| Ambient Temperature | 40 °C |
| Armature Current | 84.0 a |
| Base Indicator | Rigid |
| Duty Rating | CONT |
| Field Winding Type | STAB SHUNT |
| Frame Prefix | LC |
| Insulation Class | F |
| Mounting Arrangement | F2 |
| Service Factor | 1.00 |
| Shaft Diameter | 2.124 IN |
| Motor Standards | NEMA |
Drawings
Nameplate
| CAT.NO. | D5050RS-BV |
|---|---|
| FR | LC 2512ATZ |
| ENCL. | DP |
| ENCL MOD | FORCE VENT |
| MAX SAFE SPEED | 2250 |
| WINDING | STAB SHUNT |
| VOLTS | 300 |
| MAX AMPS @ 25 C | 3.38 |
| HOT AMPS | 2.44/1.85 |
Performance
| Rated Load |
|---|
