Description
Specs
| Base Indicator | Rigid |
|---|---|
| Bearing Grease Type | Polyrex EM (-20F +300F) |
| Drip Cover | No Drip Cover |
| Duty Rating | CONT |
| Feedback Device | NO FEEDBACK |
| Field Winding Type | STR. SHUNT |
| Frame Prefix | ULC |
| Heater Indicator | No Heater |
| Insulation Class | F |
| Lifting Lugs | Standard Lifting Lugs |
| Mounting Arrangement | F2 |
| Overall Length | 47.38 IN |
| Service Factor | 1.00 |
| Shaft Diameter | 3.249 IN |
| Shaft Extension Location | Pulley End |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Slinger Indicator | No Slinger |
| Motor Standards | NEMA |
Drawings
Nameplate
| CAT.NO. | D50250RR-BV |
|---|---|
| FR | ULC 3612ATZ |
| ENCL. | DP |
| ENCL MOD | FORCE VENT |
| MAX SAFE SPEED | 2150 |
| WINDING | STR. SHUNT |
| VOLTS | 300 |
| MAX AMPS @ 25 C | 8.87 |
| HOT AMPS | 5.91/5.38 |
Performance
| Rated Load |
|---|
